700mm Plain Slab Gloss Graphite Blind Corner Unit with 350mm Door and Right Blank - FGGR-HCBU700R

This is a 700mm high gloss graphite blind corner base unit. It consists of a 700mm matt kitchen cabinet, available in a number of different colours, a 350mm wide high gloss graphite door (pre-drilled for hinges) and a blanking panel for the right hand side. It also includes two Hettich soft close hinges and adjustable legs. It does not include a handle.

This listing includes the following parts, for you to make your blind corner base unit:

1 x 700mm cabinet

1 x 346 x 715mm door

1 x 420 blank panel

1 x 2 piece corner post

2 x 165 hinges

The corner post is supplied in flat format to allow customisation on site. In it's maximum size it measures 80 x 80 when assembled. The 80mm piece is pre-drilled on the rear face for hinge mounting plates.

The 2-part nature of the corner post is inherently flexible. The 80mm panel does not need cutting in any scenario. Position the base unit further into/out of the corner to make the 80mm panel more/less visible. Both the 61mm return post and fixing panel is trimmed and fitted accordingly.

Please click here for more information on the corner blind base units.

Standard blind corner base unit Guide to build corner base unit Corner post panels

Specifications

  • Hinge Cover Cap Included: No
  • Height: 720mm
  • Door Material: 18mm MDF laminated slab door with 1mm matching edge
  • Cabinet Back Material: 8mm Solid MFC Back
  • Back Void: 49mm
  • Cabinet Depth: 570mm
  • Height (inc legs): 870mm
  • Cabinet Assembly: Clicbox tool-less assembly
  • Door Finish: Firbeck Supergloss Graphite(Matching Matt Colour Reverse)
  • Hinges Included: Yes(Hettich 110 degree soft close)
  • Shelves Included: 1x 18mm Adjustable Shelves Included
  • Cabinet Material: 18mm MFC(matt finish)
  • Adjustable Legs: Included(Adjustment from 140 - 178mm)
  • Type: Corner Base Unit
  • Name: 700 Highline Corner Base with 350 Door (Right)
  • Product Code: FGGR-HCBU700R
  • Information: 1 x 720 Base DD 700 ClicBox White
    1 x Firbeck Supergloss Graphite Pronto Door 715x346
    1 x Standard Hettich Hinge Pack (pair) Silver CPFITT0216
    1 x 720 Base/Wall Internal Corner Post Supergloss Graphite
    1 x Corner Base Blanking Panel Pack White
  • Dimensions (mm):
  • Availability: 6 working days
  • Hinge Side(when looking from front): (Required)
  • Cabinet Colour: (Required)
    White White
    Grey Grey
    Anthracite Anthracite
    Urban Oak Urban Oak
    Dust Grey Dust Grey
    Change
  • Hinge Colour: (Required)
    Silver Silver
    Obsidian Black Obsidian Black
    Change
  • Items in Bag
  • £229.38
